Overview
The AI-Tek Instruments 70085-1010-330 is a high-performance passive speed sensor designed to deliver reliable and precise output in demanding environments. Featuring a rugged design, this sensor is suitable for applications in industrial automation, aerospace, and automotive systems.
Features
- Durable Construction: Withstands extreme temperatures from -65°C to 100°C.
- Consistent Output: Provides a standard output voltage of 54 V (P-P) with a guaranteed minimum of 13.4 V (P-P).
- Wide Application Range: Suitable for aerospace, industrial machinery, and automotive uses.
- Compact Design: Lightweight at 0.40 kg for easy integration into systems.
- Polarity Assurance: White lead indicates positive output for straightforward wiring.
Technical Specifications
- Brand: AI-Tek Instruments
- Model: 70085-1010-330
- Output Voltage: Standard 54 V (P-P), Guarantee Point 13.4 V (P-P)
- DC Resistance: Maximum 240 ohms
- Inductance: 30 mH typical reference
- Thread Length (A): 101.60 mm
- Operating Temperature Range: -65°C to 100°C
- Weight: 0.40 kg
FAQ
Q: What is the weight of the sensor?
A: The sensor weighs 0.40 kg, making it compact and easy to install.
Q: What is the maximum DC resistance?
A: The maximum DC resistance is 240 ohms.
Q: Can the sensor operate in extreme temperatures?
A: Yes, it operates reliably between -65°C and 100°C.
For more detailed information, please check official datasheet: Passive-Sensor_UL-ATEX-CSA
