Bently Nevada 330104-01-14-10-01-CN Proximity Probes

Overview

Bently Nevada manufactures the 330104-01-14-10-01-CN 3300 XL 8 mm Proximity Probe in the U.S.A. This probe is designed to measure distances without physical contact, making it highly suitable for a wide range of industrial applications. It operates effectively under specific temperature (between +18˚C and +27˚C), altitude (up to 2000 meters), and power – supply conditions.

Technical Specification

• Brand: Bently Nevada
• Product No.: 330104-01-14-10-01-CN
• Product Type: 3300 XL 8 mm Proximity Probes
• Probe Details:
  • It features an M10 x 1 thread with armor.
  • The unthreaded length is 10 mm.
  • The overall case length is 140 mm.
  • The total length is 1.0 meter (3.3 feet).
  • It comes with a Miniature coaxial ClickLoc connector having a protector and a standard cable.
  • It has country – specific approval (CN).
• Mechanical Specs:
  • The probe tip is made of Polyphenylene sulfide (PPS).
  • The probe case is constructed from AISI 303 or 304 stainless steel (SST).
  • For a 1.0 – meter probe length, the nominal DC resistance is 7.59 ± 0.50 Ω.
  • A Viton® O – ring seals the differential pressure between the probe tip and case.

Contact Information

For inquiries: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
