Bently Nevada | Proximity Probes | 330104-10-19-10-02-CN

Overview

The Bently Nevada 330104-10-19-10-02-CN 3300XL8mm Proximity Probe comes from the U.S.A. It measures the distance between the probe tip and a target. It suits various industrial uses and performs well under specific conditions.

Technical Specification

• Brand: Bently Nevada
• Product No.: 330104-10-19-10-02-CN
• Product Type: 3300XL8mm Proximity Probes
• Probe Details:
  • It has an M10 x 1 thread with armor.
  • The unthreaded length is 100mm.
  • The overall case length is 190mm.
  • The total length is 1.0 meter (3.3 feet).
  • It uses a Miniature coaxial ClickLoc connector with a standard cable.
  • It has country – specific approval (CN).
• Electrical Specifications:
  • The supply sensitivity is less than 2mV change in output voltage per volt change in input voltage.
  • The output resistance is 50Ω.
• Mechanical Specifications:
  • The probe tip is made of Polyphenylene sulfide (PPS).
  • The probe case uses AISI 303 or 304 stainless steel (SST).
  • For a 1.0m probe length, the nominal DC resistance is 7.59 ± 0.50Ω.
  • It seals differential pressure with a Viton® O – ring.

Contact Information

Contact us: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
