Proximity Probes – Bently Nevada 330101-00-20-90-02-00

Overview

The Bently Nevada 330101-00-20-90-02-00 is a 3300 XL 8 mm Probe with a 3/8 – 24 UNF thread and no armor, proudly manufactured in the U.S.A. It offers the option of adding a Certificate Of Origin. This probe and its extension cable have been improved compared to previous designs. The patented TipLoc and CableLoc technologies enhance its durability, and an optional FluidLoc cable can prevent liquid leakage.

Technical Specification

• Brand: Bently Nevada
• Model: 330101-00-20-90-02-00 (3300 XL 8 mm Probe)
• Product No. Suffix Meaning:
  • “00” indicates an unthreaded length of 0.0 inches.
  • “20” represents an overall case length of 2.0 inches.
  • “90” stands for a total length of 9.0 meters (29.5 feet).
  • “02” denotes a miniature coaxial ClickLoc connector with a standard cable.
  • “00” at the end means not required.

• Linear Range: 2 mm (80 mils), starting approximately 0.25 mm (10 mils) from the target and ranging from 0.25 to 2.3 mm (10 to 90 mils).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 303 or 304 stainless steel (SST).
• Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity for up to 56 days.
• DC Resistance: For a 9.0 – meter probe, it is 9.87 ± 0.50 Ω.

Contact Information

For any inquiries, please contact: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
