Proximity Probes Bently Nevada | 330104-00-16-10-02-CN

Overview

This product is a 3300XL 8mm Proximity Probe (330104-00-16-10-02-CN) manufactured by Bently Nevada in the U.S.A. It is designed to seal differential pressure between the probe tip and case. The probe is suitable for use in a system with a -24 Vdc power supply, a 10 kΩ load, and an AISI 4140 steel target. For inquiries, contact [email protected].

Technical Specification

• Brand: Bently Nevada
• Product No.: 330104-00-16-10-02-CN
• Product type: 3300XL 8mm Proximity Probes
• Probe Features:
  • Thread: M10 x 1 thread, with armor
  • Unthreaded Length: 00mm
  • Overall Case Length: 160mm
  • Total Length: 1.0 meter (3.3 feet)
  • Agency Approval: Country Specific Approval
• Electrical Parameters:
  • Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
  • Output Resistance: 50 Ω
  • Nominal Probe DC Resistance: For 1.0m length, 7.59 ± 0.50 Ω
• Mechanical Parameters:
  • Probe Tip Material: Polyphenylene sulfide (PPS)
  • Probe Case Material: AISI 303 or 304 stainless steel (SST)

Contact Information

For inquiries, please email: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
