1756-OF8K Allen-Bradley ControlLogix Analog Output Module

Overview

The Allen-Bradley 1756-OF8K is an analog output module designed for the ControlLogix series, offering precision and flexibility. With eight channels for voltage or current outputs, this module is equipped with a conformal coating for enhanced durability. It is suitable for applications that require high accuracy and stability, especially in industrial environments where precision is critical.

Technical Specifications

• Brand: Allen-Bradley
• Manufacturer: Rockwell Automation
• Catalog No.: 1756-OF8K
• Series: ControlLogix
• Module Type: Analog Output
• Number of Channels: 8
• Pin Count: 20 pins
• Coating: Conformal coat for added protection
• Output Ranges:
  • Voltage: -10.4V to 10.4V
  • Current: 0 to 21 mA
• Resolution:
  • 15 bits for 21-650 mA/bit
  • 15 bits for 10.4-320 V/bit
• Temperature Range:
  • Operating: 0 to 60°C
  • Non-operating: -40 to 85°C
• Humidity: 5% to 95% non-condensing
• Vibration: 2g at 10-500 Hz
• Shock:
  • Operating: 30g
  • Non-operating: 50g

Frequently Asked Questions (FAQ)

• What is the input voltage range?
  The voltage range for this module is -10.4V to 10.4V.
• How fast is the output response time?
  This module provides faster output response times, improving overall system performance.
• Is calibration required?
  No, this module does not require field calibration, making it convenient for quick installation and reliable performance.

Check official datasheet for more detailed information: ControlLogix and GuardLogix Controllers
