177230-02-01-05 Bently Nevada Seismic Transmitter

Overview:

The Bently Nevada Seismic Transmitter (Model 177230-02-01-05) is a highly accurate and reliable vibration monitoring solution, designed for industrial applications where precise seismic measurements are essential.

Technical Specifications:

• Brand: Bently Nevada
• Model: 177230-02-01-05
• Product Type: Seismic Transmitter
• Measurement Range: 0 – 50.8 mm/s (0 – 2.0 in/s)
• Frequency Range: 10 Hz to 1 kHz (600 to 60 kcps) rms
• Output Format: 4 to 20 mA current loop, velocity vibration (referenced to Pin B)
• Excitation Voltage: 12 to 30 Vdc (current limited to 40 mA)
• Electrical Isolation: Greater than 108 ohms
• Connector Type: 3-pin MIL-C-5015, 316L stainless steel
• Mounting: 1/4-28 UNF, M6 X 1 SI, M8 x 1.25 SI threads
• Case Material: 316L stainless steel
• Size: Height: 66.0 mm (2.60 in), Diameter: 25.4 mm (1.00 in)
• Weight: 131 g (4.62 oz)
• Sensitivity:
  • 0.0 to 12.7 mm/s (0 to 0.5 in/s)
  • 0.0 to 25.4 mm/s (0 to 1.0 in/s)
  • 0.0 to 50.8 mm/s (0 to 2.0 in/s), ± 10% FS, broadband rms
  • Output: 4 ± 0.3 mA equals 0.0 mm/s and 20 ± 2 mA equals 25.4 mm/s

FAQ:

1. What is the operating temperature range of the Bently Nevada Seismic Transmitter?
   The transmitter operates within a temperature range of -40°C to +85°C (-40°F to +185°F).
2. What type of output does this device provide?
   It provides a 4 to 20 mA current loop output, representing velocity vibration.
3. Is the Bently Nevada Seismic Transmitter certified for safety?
   Yes, it has multiple approvals including CSA/NRTL/C and ATEX/IECEx.
4. What is the mounting type for the transmitter?
   The transmitter supports M6 X 1 SI, M8 x 1.25 SI, and ¼-28 UNF threads for mounting.
5. How sensitive is the Seismic Transmitter?
   It has sensitivity ranges from 0.0 to 50.8 mm/s (0 to 2.0 in/s) with a broadband rms accuracy of ± 10% FS.

For more detailed information, please check official datasheet: 177230 Seismic Transmitter Datasheet
