177230-02-01-CN Bently Nevada Seismic Transmitter

Overview:

The Bently Nevada 177230-02-01-CN Seismic Transmitter is designed for precision vibration measurement and monitoring in industrial environments. Manufactured in the USA, it is built to withstand harsh conditions, offering a robust solution for velocity and vibration analysis. With its 316L stainless steel casing and 3-pin MIL-C-5015 connector, it is engineered for reliability and durability in demanding applications.

Technical Specifications:

• Brand: Bently Nevada
• Model: 177230-02-01-CN
• Connector: 3-pin MIL-C-5015, stainless steel
• Case Material: 316L stainless steel
• Mounting: ¼-28 UNF, M6 x 1 SI, M8 x 1.25 SI
• Weight: 131 g (4.62 oz)
• Dimensions: Height: 66.0 mm (2.60 in), Diameter: 25.4 mm (1.00 in)
• Power Supply: 12 to 30 VDC (current limited to 40 mA)
• Sensitivity Range: 0.0 to 50.8 mm/s (0 to 2.0 in/s), ± 10% FS, broadband rms
• Frequency Response: 2.5 Hz to 10 kHz (150 cpm to 600 kcpm), ± 10% linearity
• Resonant Frequency: Greater than 12 kHz
• Transverse Sensitivity: Less than 5% of sensitivity
• Sensing Element: Ceramic/Shear

FAQ:

1. What is the purpose of the Bently Nevada 177230-02-01-CN Seismic Transmitter?
   • The device is used to monitor vibration and velocity in industrial systems, providing real-time data on the condition of equipment and machinery.
2. What is the output signal of this transmitter?
   • The transmitter provides a 4-20 mA current loop output, referenced to Pin B, which is used for velocity vibration measurement.
3. What is the recommended power supply for this product?
   • The Bently Nevada Seismic Transmitter operates with a 12 to 30 VDC power supply, with a current limited to 40 mA.
4. Can the transmitter be used in harsh environments?
   • Yes, the product is housed in a durable 316L stainless steel case, making it suitable for industrial environments where corrosion resistance is essential.

For more detailed information, please check official datasheet: 177230 Seismic Transmitter Datasheet
