21000-28-05-00-050-03-02 | 21000 Proximity Probe Housing Assemblies

Overview

The Bently Nevada 21000-28-05-00-050-03-02 Proximity Probe Housing Assemblies are designed for use in harsh industrial environments, ensuring the safe and reliable operation of proximity probes in hazardous areas. With CSA approvals and an explosion-proof rating, these assemblies are suitable for intrinsically safe applications. The assembly comes with a reverse mount proximity probe, aluminum body with a stainless steel sleeve, and various customizable options such as probe length and mounting thread.

Technical Specifications

• Brand: Bently Nevada
• Model: 21000 Proximity Probe Housing Assembly
• Material: Aluminum body with 304 stainless steel sleeve
• Probe Type: 3300 XL 8 mm reverse mount proximity probe
• Fittings: 3/4-14 NPT plug, 3/4-14 to 1/2-14 NPT reducer, cable seal grip with grommets
• Mounting Thread Option: 3/4-14 NPT (mandatory with non-zero standoff adapter length)
• Approvals: CSA certified for hazardous areas, explosion proof, API 670 compliant

21000-28-05-00-050-03-02 Ordering Information

• Model Number: 21000 – AA-BB-CC-DDD-EE-FF
  • A: Probe with connector (28 3300 XL 8 mm probe)
  • B: Probe cable length (05: 0.5 m)
  • C: Standoff adapter length (00 for no adapter)
  • D: Probe penetration (e.g., -050 for 5 in)
  • E: Fittings option (03 includes plugs and reducers)
  • F: Mounting thread (02: 3/4-14 NPT (Must be ordered if Standoff Adapter Length Option is not -00)

Check official datasheet for more detailed information:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
