21000-28-05-00-064-04-02 | Proximity Probe Housing Assemblies

Overview

The Bently Nevada 21000-28-05-00-064-04-02 Proximity Probe Housing Assembly delivers high-performance monitoring in hazardous environments. It provides accurate vibration monitoring and is ideal for applications that require CSA certifications for explosion-proof enclosures. The assembly consists of an aluminum body with a 304 stainless steel sleeve, providing durability and resistance to harsh conditions. Ideal for industrial automation, it offers a combination of safety, precision, and versatility in proximity monitoring systems.

Technical Specifications

• Brand: Bently Nevada
• Model: 21000 Proximity Probe Housing Assembly
• Material: Aluminum body with a 304 stainless steel sleeve
• Dimensions: Maximum cable length of 0.5 m (20 in); visible probe length up to 13.5 in (34.3 cm)
• Weight: 1.1 kg (2.4 lb) without fittings
• Mounting Thread: 3/4-14 NPT
• CSA Certifications: Explosion-proof when ordered with specific options (E:00, E:01, E:02, E:04)

21000-28-05-00-064-04-02 Ordering Information & Suffix Codes

• Probe Option: -28 (3300 XL 8 mm probe, selectable for hazardous area approvals)
• Probe Cable Length: -05 (0.5 m)
• Standoff Adapter: -00 (No standoff adapter)
• Probe Penetration: -064 (6.4 in)
• Fitting Option: -04 (One 3/4-14 NPT plug)
• Mounting Thread Option: -02 (3/4-14 NPT)

Note: Explosion-proof fittings available for all housings, but CSA ratings apply only when specific options are selected.

Check official datasheet for more detailed information:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
