21000-28-10-30-018-04-02 21000 Proximity Probe | Housing Assemblies

Overview:

The Bently Nevada 21000-28-10-30-018-04-02 Proximity Probe Housing Assemblies are designed for industrial machinery monitoring, ensuring robust and reliable performance in harsh environments. These assemblies come with an aluminum body and a 304 stainless steel sleeve, offering exceptional durability. The 21000 model features a reverse mount proximity probe and is fully compliant with safety standards, making it suitable for hazardous area applications. Additionally, the housing is certified as a CSA Type 4 enclosure, meeting the stringent requirements of the API 670 Standard for externally mounted proximity probes.

Ordering Information:

To specify the desired configuration, the following model number structure applies:

• 21000 – AA-BB-CC-DDD-EE-FF

Where:

• A: Probe with Connector ( 28 3300 XL 8 mm probe, selectable hazardous area approvals)
• B: Probe Cable Length (10 for 1.0 m cable)
• C: Standoff Adapter Length (30 for 3 in)
• D: Probe Penetration (-018 for 1.8 in penetration)
• E: Fittings Option (04 for 3/4-14 NPT plug only)
• F: Mounting Thread Option (-02 for 3/4-14 NPT)

Technical Specifications:

• Model: 21000
• Manufacturer: Bently Nevada
• Part Number: 21000-28-10-30-018-04-02
• Material: Aluminum body, 304 stainless steel sleeve
• Weight: 1.1 kg (2.4 lb) without fittings
• Maximum Dimensions:
  • Probe Penetration: 1.8 in (46 mm)
  • Total Length (C + D): 13.5 in (34.3 cm)
• Approval: CSA, API 670, Explosion proof, Intrinsically safe
• Warranty: 12 months

Check official datasheet for more detailed information:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
