22F-A4P2N103 Allen-Bradley PowerFlex 4M AC Drive

Overview

The Allen-Bradley 22F-A4P2N103 is a high-performance industrial AC drive designed for use with single-phase and three-phase AC voltage. A part of the PowerFlex 4M series, it offers flexibility and energy efficiency for various applications requiring precise motor control.

Features:

• Energy Efficiency: Supports single-phase input (200-240V AC) and three-phase output (up to 230V AC).
• Operating Frequency: Works with a frequency range of 50 to 60 Hertz, making it suitable for diverse operational environments.
• Compact Design: Designed with an open, IP20-rated enclosure for easy installation in standard electrical cabinets.
• Power Rating: 0.75 kW (1 horsepower), ideal for medium-duty applications.
• Amperage: Rated for 4.2 Amps, providing efficient motor performance.

Technical Specifications:

• Brand: Allen-Bradley
• Model: 22F-A4P2N103
• Part Number: 22F-A4P2N103
• PowerFlex Series: PowerFlex 4M
• Input Voltage: 240V AC (single-phase)
• Output Voltage: 0 to 230V AC (three-phase)
• Frequency Range: 50-60 Hz
• Amperage: 4.2 A
• Horsepower: 1 HP
• Wattage: 0.75 kW
• Enclosure: Open, IP20
• Filter: No CE Compliant Filter

FAQ:

1. What voltage can the 22F-A4P2N103 AC drive handle?
   • It supports 200-240V AC single-phase input and up to 230V AC three-phase output.
2. Can the drive operate in different frequencies?
   • Yes, it operates in a frequency range of 50 to 60 Hz.
3. Is the 22F-A4P2N103 compatible with all motors?
   • It is designed for use with a variety of motors in industrial applications, primarily where variable speed is required.

Check official datasheet for more detailed information: PowerFlex 4M Adjustable Frequency AC Drive
