24765-03-00 Bently Nevada Case Expansion Transducer Assembly

Overview:

The Bently Nevada 24765-03-00 Case Expansion Transducer Assembly is designed for precise measurement of case expansion in machinery. With a linear range of 101.6 mm (4.00 in) and a scale factor of 0.143 V/mm, it ensures reliable and accurate data. Made in the USA, this assembly offers a stability of 0.125% full-scale, making it a preferred choice for critical applications in vibration monitoring.

Features:

• Manufacturer: Bently Nevada
• Product Type: Case Expansion Transducer Assembly (dc)
• Linear Range: 101.6 mm (4.00 in)
• Scale Factor: 0.143 V/mm (3.63 V/in)
• Stability: 0.125% full-scale
• Frequency Response: -3 dB at 10 Hz
• Linearity: ±0.5% full-range
• Spring Option: No spring return (0 0)
• Made in U.S.A with optional Certificate of Origin (COO)
• Height: 88.9 mm (3.50 in)
• Width: 117 mm (4.60 in)
• Length: 328 mm (12.90 in)
• Weight: 2.7 kg (6.0 lbs)

Technical Specifications:

• Brand: Bently Nevada
• Model: 24765-03-00
• Linear Range: 101.6 mm (4.00 in)
• Scale Factor: 0.143 V/mm (3.63 V/in)
• -3 dB Frequency: 10 Hz
• Linearity: ±0.5% full-range
• Stability: 0.125% full-scale
• Spring Option: No spring return
• Height: 88.9 mm (3.50 in)
• Width: 117 mm (4.60 in)
• Length: 328 mm (12.90 in)
• Weight: 2.7 kg (6.0 lbs)

Applications:

The 24765-03-00 Case Expansion Transducer Assembly is widely used in industries such as vibration monitoring, machinery protection, and diagnostics for critical rotating equipment. It is ideal for systems requiring precise case displacement measurements for preventive maintenance and condition monitoring.

FAQ:

1. What is the linear range of the 24765-03-00 transducer?
   The linear range is 101.6 mm (4.00 in), providing accurate displacement readings.
2. What is the frequency response of this transducer?
   The -3 dB frequency response is 10 Hz, ensuring high-performance measurement even at low frequencies.
3. Does this transducer have a spring return?
   No, it does not include a spring return, providing greater flexibility in installation.

Check official datasheet for more detailed information: Case Expansion Transducer Systems
