25A-E3P0N104 Allen-Bradley AC Drive 600V AC 3 Phase

Overview:

The Allen-Bradley 25A-E3P0N104 is a part of the PowerFlex 523 series of variable frequency drives, designed for controlling industrial motors efficiently. It is a robust and reliable solution with the flexibility to handle a variety of applications. Its advanced features and versatile configuration options make it ideal for use in a range of factory and industrial environments.

Key Features:

• PowerFlex 523 Series: Offers multiple control methods like Volts/Hertz, Sensorless Vector Control, and Closed Loop Velocity Vector Control.
• Input Voltage Range: 525-600 VAC, 3-phase, with a tolerance of -15% to +10%.
• Output Power: Delivers 2 HP (1.5 kW) for both normal and heavy-duty operation.
• Enclosure: IP20, NEMA / Open Type, suitable for panel or DIN rail mounting.
• Output Current: 3 Amps, with an output frequency range of 0-500 Hz.
• Embedded I/O: Includes discrete and analog inputs/outputs for flexible integration.
• Efficiency: 97.5% for reduced energy consumption.
• Communication: Built-in RS485 for seamless connectivity.

Technical Specifications:

• Brand: Allen-Bradley
• Model: 25A-E3P0N104
• Series: PowerFlex 523
• Voltage: 600V AC, 3-phase input, 0-575V AC, 3-phase output.
• Current Rating: 3.0 Amps
• Frame Size: A
• Output Power: 1.5 kW (2 HP)
• Enclosure: IP20, NEMA / Open Type
• Control Methods: V/Hz, Sensorless Vector, Closed Loop Velocity Vector
• Output Frequency: 0-500 Hz
• Embedded I/O: 5 Discrete Inputs, 1 N.O. and 1 N.C. Discrete Output, 2 Analog Inputs (0-10VDC, 0-20mA), 1 Analog Output (0-10VDC, 0-20mA)
• Protection Features: Overload protection, ground fault, overvoltage, and undervoltage trips.
• Application: Suitable for industrial motor control, factory automation, HVAC systems, conveyor systems, and more.

FAQ:

1. What is the maximum output current of the 25A-E3P0N104?
   • The output current is 3 Amps.
2. What is the voltage range for the input?
   • The input voltage range is 525-600 VAC, 3-phase.
3. What is the output power of this drive?
   • The drive provides 1.5 kW (2 HP) for both normal and heavy-duty applications.
4. Does this model include protection features?
   • Yes, it includes electronic overload protection, overcurrent trip, ground fault, and over/undervoltage protection.
5. How can I mount the drive?
   • The drive can be mounted on a panel or DIN rail.
6. What communication options does the drive support?
   • It has a built-in RS485 communication port.

Check official datasheet for more detailed information: PowerFlex 520-series AC Drive
