3300 XL 8 mm 330105-02-12-15-12-05 Proximity Probe

Overview

The Bently Nevada 3300 XL 8 mm Reverse Mount Probe (330105-02-12-15-12-05) is designed for reliable vibration monitoring in critical machinery applications. It features high precision and durability, with a range of approvals and temperature capabilities, ensuring long-term reliability even in harsh conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Reverse Mount Probe
• Product Number: 330105-02-12-15-12-05
• Thread Type: 3/8-24 UNF
• Total Length Option: 15 1.5 meters (4.9 feet)
• Connector: 12 Miniature ClickLoc coaxial connector with FluidLoc cable
• Weight: 0.323 kg
• Maximum Thread Engagement: 0.563 in
• Agency Approvals: CSA, ATEX, IECEx

Application

Ideal for use in vibration monitoring systems across industries like power generation, oil and gas, and mining, the 3300 XL Reverse Mount Probe offers exceptional accuracy in detecting machinery imbalances, alignment issues, and other critical mechanical faults.

FAQ

Q: What temperature range can the probe withstand?
A: The standard probe can operate from -52°C to +177°C (-62°F to +350°F). The extended temperature range option can handle -52°C to +218°C (-62°F to +425°F) for the probe tip and -51°C to +260°C (-60°F to +500°F) for the cable and connector.

Q: Can this probe be used in hazardous environments?
A: Yes, it is CSA, ATEX, and IECEx approved, making it suitable for use in hazardous locations.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
