Product details
Bently Nevada 3300 XL 8 mm Probe: Model 330101-00-12-10-01-CN
Key Identifier: 330101-00-12-10-01-CN
Industrial-grade vibration monitoring probe with 3/8-24 UNF thread and 8 mm PPS tip. Features a ClickLoc connector with protector and patented CableLoc design (330 N pull strength). Optional FluidLoc cable prevents oil leakage in harsh environments.
Suffix Configuration
| 00 | 0.0 in unthreaded length |
| 12 | 1.2 in case length |
| 10 | 1.0 m (3.3 ft) total cable |
| 01 | ClickLoc connector with protector |
| CN | Country-specific certifications |
Technical Specifications
| Brand | Bently Nevada |
| DC Resistance | 7.59Ω ±0.50 @1.0m |
| Temperature Range | -62°F to +500°F (cable/connector) |
| Linear Range | 0.25–2.3 mm (10–90 mils) |
| Accuracy | ±0.025mm linear deviation |
| Housing | AISI 303/304 stainless steel |
Key Advantages
- Durability: 8mm PPS tip resists mechanical stress
- Humidity Resistance: <3% ASF drift @93% RH (56 days, IEC 68-2-3)
- Extended Wiring: Supports 305m shielded triad cables
- Seal Integrity: Viton O-ring (custom pressure testing available)
Contact: For inquiries or customization: sales@ubestplc.com
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
