3300 XL 8 mm Reverse Mount Probe 330105-02-12-10-12-05

Overview

The Bently Nevada 3300 XL 8 mm Reverse Mount Probes are high-precision sensors for reliable proximity measurement in industrial applications. These probes have been updated with a new replacement model: 330105-02-12-10-02-CN. The original model, 330105-02-12-10-02-05, is now discontinued.

General Specifications

• Product Number: 330105-02-12-10-02-05
• Weight: 0.323 kg
• Connector Option: Miniature ClickLoc™ coaxial connector (02)
• Total Length Option: 1.0 meter (10)
• Agency Approval Option: Multiple Approvals (05)
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)

Thread Engagement Length

• Maximum Length of Thread Engagement: 3/8-24 thread, 0.563 inches

Temperature Range

• Standard Probe: -52°C to +177°C (-62°F to +350°F)
• Extended Temperature Range Probe:
  • Probe Tip: -52°C to +218°C (-62°F to +425°F)
  • Probe Cable and Connector: -51°C to +260°C (-60°F to +500°F)

Performance Characteristics

• Operating Temperature: Between +18°C and +27°C (+64°F to +80°F)
• Maximum Altitude: 2000 meters
• Power Supply: -24 Vdc
• Load: 10 kΩ
• Target Material: AISI 4140 steel
• Gap Distance: 1.27 mm (50 mils)

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
