3300 XL Extension Cable 330730-080-00-05 | Bently Nevada

Overview:

The Bently Nevada 330730-080-00-05 3300 XL 11 mm Extension Cable is a robust solution designed for use with the 3300 XL Proximitor Sensors and provides reliable signal transmission in industrial environments. Manufactured in the U.S.A, this cable features a flexible, durable construction with various optional features such as cable armor and connector protection, making it ideal for harsh conditions. The cable’s high-performance characteristics include multiple approvals, ensuring it meets industry standards for safety and reliability.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Extension Cable
• Product Number: 330730-080-00-05
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Extension Cable Armor (Optional): Flexible AISI 302 SST with FEP outer jacket
• Operating Temperature: -52°C to +177°C (-62°F to +351°F)
• Storage Temperature: -51°C to +177°C (-60°F to +351°F)
• Extension Cable Weight: 45 g/m (0.5 oz/ft) without armor, 0.36kg
• Tensile Strength: 330 N (75 pounds) probe case to probe lead; 270 N (60 pounds) at probe lead to extension cable connectors
• Connector Material: Gold-plated brass
• FluidLoc Cable Option: Available for preventing leakage of oils and other liquids
• Connector Protector: Optional for increased environmental protection

Ordering Information:

When ordering the Bently Nevada 3300 XL 11 mm Extension Cable, specify the following details:

• Length: 8.0 meters (standard length)
• Cable Option: Standard cable or optional fluid-resistant cable
• Approval: Choose from available approval options
• Armor Option: Choose flexible AISI 302 SST with FEP outer jacket for additional protection

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
