Overview
The Bently Nevada 3300 XL Extension Cable (Product No. 330130-045-01-05) is a high-quality accessory designed for use with the 3300 XL 8 mm proximity probes and sensors. Manufactured in the U.S.A., this cable offers a reliable connection for industrial vibration monitoring systems. The extension cable is built to provide durability and performance in harsh environments, ensuring long-lasting operational stability. Its armored cable construction enhances the protection of the system, while the CSA, ATEX, and IECEx approvals make it suitable for a wide range of industrial applications.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL Extension Cable
- Product Number: 330130-045-01-05
- Cable Length: 4.5 meters (14.8 feet)
- Connector Protector & Cable Option: Armored cable (01)
- Agency Approval Option: CSA, ATEX, IECEx (05)
- Temperature Range: Operating and storage temperatures from -51°C to +177°C (-60°F to +351°F)
- Weight: 0.948 kg
- Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
- Field Wiring: Supports 0.2 to 1.5 mm² (16 to 24 AWG) with recommended 3-conductor shielded triad cable
- Maximum Length: 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and monitor
- Linear Range: 2 mm (80 mils), starts at approximately 0.25 mm (10 mils) and ends at 2.3 mm (90 mils)
- Power Requirements: Requires -17.5 Vdc to -26 Vdc with nonincendive circuit; consumption of 12 mA maximum
FAQs
- 1. What is the maximum cable length?
- The maximum length for the extension cable is 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitor.
- 3. What is the operating temperature range for the cable?
- The cable can operate in temperatures ranging from -51°C to +177°C (-60°F to +351°F).
- 4. Does this cable come with agency approvals?
- Yes, the cable is approved by CSA, ATEX, and IECEx, making it suitable for use in hazardous locations.
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
