3300 XL Extension Cable Bently Nevada 330130-075-00-CN

Overview

The Bently Nevada 330130-075-00-CN is a 3300 XL Extension Cable designed to meet the highest industry standards. Built in the U.S.A., it features advanced capabilities for reliable and robust connectivity. With an optional Certificate of Origin (COO) available, this cable ensures compliance with specific requirements. The 3300 XL series reflects patented design improvements, including TipLoc molding and CableLoc technology, providing enhanced durability and performance.

Features and Technical Specifications

• Brand and Model: Bently Nevada 330130-075-00-CN
• Cable Length Option: 075 = 7.5 meters (24.6 feet)
• Connector Protector and Cable Option: 00 = Standard cable protectors
• Agency Approval Option: CN = Country-specific approvals
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Operating Temperature: -51 °C to +177 °C (-60 °F to +351 °F)
• Storage Temperature: Same as operating temperature
• Weight: 0.83 kg
• Linear Range: From approximately 0.25 mm (10 mils) to 2.3 mm (90 mils), with a linear range beginning at 0.25 mm (10 mils).
• Power Requirements: -17.5 Vdc to -26 Vdc at 12 mA max consumption.
• Output Resistance: 50 Ω
• Field Wiring: Supports 16 to 24 AWG shielded triad cables, with a maximum length of 305 meters (1,000 feet).

Significance of Suffix Codes

1. 075: Indicates the cable length of 7.5 meters.
2. 00: Refers to standard cable protectors.
3. CN: Denotes country-specific agency approvals.

FAQ

• 1. What is the primary use of the 330130-075-00-CN extension cable?
  The cable is designed for use with 3300 XL 8 mm Proximitor Sensors to extend the signal between the sensor and the monitoring device.
• 2. Is the cable compatible with non-standard targets?
  The system is optimized for AISI 4140 steel targets, and accuracy may vary with other materials.
• 3. What makes this cable durable?
  The patented TipLoc and CableLoc technologies ensure a robust bond and high pull strength for long-lasting performance.
• 4. Can the cable withstand extreme temperatures?
  Yes, it operates between -51 °C to +177 °C (-60 °F to +351 °F).

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
