3300 XL FluidLoc Cable 330130-030-12-05 | Bently Nevada

Overview

The Bently Nevada 330130-030-12-05 is a high-performance extension cable designed for use with 3300 XL Proximitor Sensors and probes. Known for its robust construction and enhanced features, this cable is ideal for industrial environments requiring precise vibration monitoring. The inclusion of a patented FluidLoc cable option ensures that liquids do not leak through the cable’s interior, enhancing reliability in harsh conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 330130-030-12-05
• Product Type: 3300 XL Extension Cable
• Country of Origin: Made in U.S.A
• Cable Length Option: 030 – 3.0 meters (9.8 feet)
• Connector Protector and Cable Option: 12 – FluidLoc cable with connector protector
• Agency Approval Option: 05 – CSA, ATEX, IECEx Approvals
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Operating and Storage Temperature: -51°C to +177°C (-60°F to +351°F)
• Weight: 0.102 kg (34 g/m or 0.4 oz/ft)

Connector Details

The 330130-030-12-05 cable features two types of connectors:

• 3300 XL Gold “Click” Connectors: Require finger-tightening.
• Non-XL Stainless Steel Connector: Requires finger-tightening plus an additional 1/8 turn using pliers for secure attachment.

Connector Materials:

• Gold-plated brass or gold-plated beryllium copper.

Electrical Specifications

• Power Requirements: -17.5 Vdc to -26 Vdc with a 12 mA maximum consumption. Operation with barriers requires -23 Vdc to -26 Vdc.
• Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
• Output Resistance: 50 Ω.
• Linear Range: 2 mm (80 mils), beginning at approximately 0.25 mm (10 mils) from the target.

Frequently Asked Questions (FAQ)

• Q: What is the purpose of the FluidLoc option?
• A: The FluidLoc option prevents liquids from leaking through the interior of the cable, enhancing the reliability of the system in environments with potential fluid exposure.
• Q: Can this cable be used with non-XL connectors?
• A: Yes, the cable is compatible with one non-XL stainless steel connector and one 3300 XL connector.
• Q: What is the typical capacitance of this cable?
• A: The typical capacitance is 69.9 pF/m (21.3 pF/ft).
• Q: What are the operating temperature limits?
• A: The cable can operate within a temperature range of -51°C to +177°C (-60°F to +351°F).

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
