3300 XL Proximitor Sensor | 330780-91-CN Bently Nevada

Overview

The Bently Nevada 3300 XL 11 mm Proximitor Sensor (Product No. 330780-91-CN) is designed for precise measurement in demanding environments. This sensor, featuring a slim and efficient design, offers flexibility with installation options, including high-density DIN-rail and traditional panel mounts. It boasts improved RFI/EMI immunity, ensuring robust performance even in environments with high-frequency radio signals.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Proximitor Sensor
• Suffix: CN (Country Specific)
• Dimensions: 6.35 cm (H) x 6.12 cm (W) x 8.13 cm (D)
• Mounting Options: DIN mount, panel mount
• System Length: 5 meters or 9 meters (including extension cable)
• Material: A380 aluminum
• Power Requirements: -17.5 Vdc to -26 Vdc (12 mA maximum consumption)
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ω
• Temperature Range:
  • Operating: -52°C to +100°C (-62°F to +212°F)
  • Storage: -52°C to +105°C (-62°F to +221°F)
• Agency Approval: CN (Country Specific)

FAQ

• Q: What is the maximum operating temperature for the 330780-91-CN?
  A: The operating temperature ranges from -52°C to +100°C (-62°F to +212°F).
• Q: Is this sensor compatible with any probe?
  A: Yes, it accepts one non-contacting 3300 XL 11 mm Proximity Probe and Extension Cable.

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
