3300 XL Proximity Probe 330104-00-04-10-02-CN Bently Nevada

Overview

The Bently Nevada 3300 XL 8 mm Proximity Probe (Product No. 330104-00-04-10-02-CN) is designed for high-precision vibration measurement and monitoring applications. Manufactured in the U.S.A, this probe features enhanced sealing and cable technologies, making it a reliable choice for industrial environments. With its robust design and advanced materials, it provides precise measurements, ensuring the safety and efficiency of machinery. The probe is available with various customization options, such as a miniature coaxial ClickLoc™ connector and fluid-resistant cables.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Product Number: 330104-00-04-10-02-CN
• Suffix Meaning:
  • 00: Unthreaded Length (0 mm)
  • 04: Overall Case Length (40 mm)
  • 10: Total Length (1.0 metre / 3.3 feet)
  • 02: Connector and Cable Type (Miniature coaxial ClickLoc™ connector, standard cable)
  • CN: Agency Approval (Country Specific)

Materials & Construction

• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Sealing Material: Viton® O-ring
• Weight: 0.323 kg

Temperature & Humidity Range

• Standard Probe: -52°C to +177°C (-62°F to +350°F)
• Extended Temperature Range:
  • Probe Tip: -52°C to +218°C (-62°F to +425°F)
  • Probe Cable & Connector: -51°C to +260°C (-60°F to +500°F)
• Humidity: Less than a 3% change in Average Scale Factor (ASF) when tested at 93% humidity for up to 56 days

Performance Characteristics

• Power Supply: Requires -17.5 Vdc to -26 Vdc (maximum 12 mA consumption)
• Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ω
• Probe Pressure: Sealed differential pressure design
• Cable Pull Strength: 330 N (75 lbf)

Cable Options:

• FluidLoc cable option available to prevent leakage of oils and liquids through the cable interior

FAQ

1. What is the maximum temperature range for the 3300 XL 8 mm Proximity Probe?
   • The standard probe operates from -52°C to +177°C (-62°F to +350°F), while the extended version can withstand up to +218°C (+425°F) for the probe tip and +260°C (+500°F) for the probe cable.
2. How is the probe sealed?
   • The probe features a Viton® O-ring for differential pressure sealing between the probe tip and case.
3. What is the purpose of the FluidLoc cable option?
   • This option prevents oil and other liquids from leaking out of machinery through the cable’s interior, ensuring more reliable performance in wet or contaminated environments.
4. What is the power supply requirement for the 3300 XL probe?
   • It requires a power supply between -17.5 Vdc to -26 Vdc, with a maximum consumption of 12 mA.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
