3300 XL Proximity Probe 330104-00-13-10-02-00 Bently Nevada

Overview

The Bently Nevada 3300 XL 8 mm Proximity Probe (model number: 330104-00-13-10-02-00) is designed for precise and reliable vibration monitoring in industrial applications. It features advanced materials and robust construction, ensuring longevity and accuracy. Manufactured in the U.S.A, this probe is built to withstand harsh environments and offers high resistance to pressure, temperature variations, and environmental factors.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Part Number: 330104-00-13-10-02-00
• Made in: U.S.A
• Weight: 0.323 kg
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Probe Tip Pressure Seal: Viton® O-ring (not pressure tested prior to shipment)
• Cable Option: Miniature coaxial ClickLoc™ connector, standard cable
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe: -52°C to +218°C (-62°F to +425°F) for the probe tip; -51°C to +260°C (-60°F to +500°F) for the probe cable and connector.
• Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) at 93% humidity (up to 56 days, in accordance with IEC standard 68 2 3)
• Pressure Rating: Seals differential pressure between probe tip and case.
• Cable Pull Strength: 330 N (75 lbf), with patented CableLoc design for secure attachment.
• Power Requirement: -17.5 Vdc to -26 Vdc with 12 mA maximum consumption, or -23 Vdc to -26 Vdc with barriers. Operation at voltages more positive than -23.5 Vdc may reduce linear range.
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
• Output Resistance: 50 Ω
• Probe Gapping: Typically gapped at 1.27 mm (50 mils) when installed with AISI 4140 steel target.

330104-00-13-10-02-00 Suffix Meaning:

• 00: Unthreaded Length Option (0 mm)
• 13: Overall Case Length Option (130 mm)
• 10: Total Length Option (1.0 meter or 3.3 feet)
• 02: Connector and Cable-Type Option (Miniature coaxial ClickLoc™ connector, standard cable)
• 00: Agency Approval Option (Not required)

Frequently Asked Questions (FAQ)

1. What is the typical operating temperature range for the 3300 XL 8 mm Proximity Probe?
   • The standard probe operates between -52°C to +177°C (-62°F to +350°F), with an extended range available up to +425°F for the probe tip.
2. Can the 3300 XL probes handle high-pressure environments?
   • Yes, the probes are designed to seal differential pressure, though they are not pressure-tested before shipment.
3. What is the cable pull strength for this probe?
   • The probe’s cable has a patented CableLoc design that provides 330 N (75 lbf) pull strength.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
