3300 XL Proximity Probe Bently Nevada 330104-00-05-05-02-05

Overview

The Bently Nevada 330104-00-05-05-02-05 3300 XL 8 mm Proximity Probe is designed for reliable and precise vibration monitoring in industrial machinery. This high-performance probe is a key component in predictive maintenance and condition monitoring systems. Manufactured using durable materials, including stainless steel for the probe case and polyphenylene sulfide (PPS) for the tip, it ensures long-lasting performance even in harsh environments.

Key Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Product No.: 330104-00-05-05-02-05
• Material:
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 303 or 304 stainless steel (SST)
• Connector and Cable: Miniature coaxial ClickLoc™ connector with standard cable
• Weight: 0.323 kg
• Overall Length: 0.5 meters (1.6 feet)
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range: Probe Tip: -52°C to +218°C (-62°F to +425°F); Probe Cable & Connector: -51°C to +260°C (-60°F to +500°F)
• Pressure Seal: Viton® O-ring (sealed differential pressure between probe tip and case)
• Power Supply:
  • Requires -17.5 Vdc to -26 Vdc with 12 mA max current consumption
  • Operation with barriers at -23 Vdc to -26 Vdc
• Output Resistance: 50 Ω
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Humidity: Less than 3% change in Average Scale Factor (ASF) at 93% humidity

Model Code Breakdown

• 330104: Model Number
• 00: Unthreaded Length (0 mm)
• 05: Overall Case Length (50 mm)
• 05: Total Length (0.5 meters)
• 02: Connector and Cable Type (Miniature coaxial ClickLoc™)
• 05: Agency Approval (CSA, ATEX, IECEx)

FAQ

• Q: What materials are used in the construction of the Bently Nevada 3300 XL probe?
  A: The probe tip is made of Polyphenylene Sulfide (PPS), while the probe case is constructed from durable AISI 303 or 304 stainless steel.
• Q: What are the temperature and humidity tolerances of the 3300 XL 8 mm probe?
  A: The standard temperature range is from -52°C to +177°C (-62°F to +350°F), with an extended range for the probe tip reaching +218°C. The probe has a high tolerance to humidity with less than a 3% change in Average Scale Factor after exposure to 93% humidity for up to 56 days.
• Q: Can the probe be used in hazardous environments?
  A: Yes, the probe has CSA, ATEX, and IECEx certifications, making it suitable for hazardous locations.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
