3300 XL Proximity Probe Bently Nevada 330104-00-08-10-01-05

Overview:

The Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330104-00-08-10-01-05) is designed for high-performance vibration monitoring and machinery protection systems. Manufactured in the U.S.A, it offers precise and reliable measurements for rotating machinery, ensuring operational efficiency and safety. This probe is widely used in industrial applications, particularly in turbine and generator monitoring systems.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Part Number: 330104-00-08-10-01-05
• Made in: U.S.A
• Unthreaded Length Option: 00 = 0 mm
• Overall Case Length Option: 08 = 80 mm
• Total Length Option: 10 = 1.0 metre (3.3 feet)
• Connector and Cable-Type Option: 01 = Miniature coaxial ClickLoc connector with connector protector and standard cable
• Agency Approval Option: 05 = CSA, ATEX, IECEx approvals
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Pressure Sealing: Viton® O-ring seals the differential pressure between the probe tip and case.
• Weight: 0.323 kg
• Operating Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe: -52°C to +218°C (-62°F to +425°F) for the probe tip; -51°C to +260°C (-60°F to +500°F) for the probe cable and connector
• Humidity Resistance: Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity for up to 56 days
• Power Supply: Requires -17.5 Vdc to -26 Vdc (12 mA max consumption) with nonincendive circuit, or -23 Vdc to -26 Vdc with barriers
• Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ω

FAQ:

1. What is the maximum operating temperature of the 3300 XL probe?
   • The standard probe operates within -52°C to +177°C, and the extended range probe reaches up to +425°F for the tip and +500°F for the cable and connector.
2. Can I use this probe in hazardous environments?
   • Yes, the probe is CSA, ATEX, and IECEx certified, making it suitable for use in explosive atmospheres.
3. How accurate is the 3300 XL 8 mm proximity probe?
   • The probe ensures precise gap measurements, with performance characteristics verified for systems that use 3300 XL components.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
