3300 XL Proximity Probe Bently Nevada 330104-00-10-10-02-00

Overview:

The Bently Nevada 330104-00-10-10-02-00 8 mm Proximity Probe is designed for high-performance vibration monitoring and displacement measurement. With advanced features like robust construction and reliable sealing, this probe is ideal for various industrial applications. It provides excellent accuracy, ensuring effective machine monitoring and maintenance.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Part Number: 330104-00-10-10-02-00
• Made in: U.S.A
• Weight: 0.323 kg
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Probe Pressure: Seals differential pressure between the probe tip and case with a Viton® O-ring (not pressure tested prior to shipment)
• Connector and Cable-Type Option: 02 – Miniature coaxial ClickLoc™ connector with standard cable
• Unthreaded Length Option: 00 – 0mm
• Overall Case Length Option: 10 – 100mm
• Total Length Option: 10 – 1.0 metre (3.3 feet)
• Agency Approval Option: 00 – Not required
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe:
    • Probe Tip: -52°C to +218°C (-62°F to +425°F)
    • Probe Cable and Connector: -51°C to +260°C (-60°F to +500°F)
• Power Requirement: -17.5 Vdc to -26 Vdc with a maximum consumption of 12 mA
• Supply Sensitivity: Less than 2 mV change per volt change in input voltage
• Output Resistance: 50 Ω

FAQ:

• Q1: What is the range of operating temperatures for the 3300 XL 8 mm Proximity Probe?
  A1: The standard probe operates between -52°C to +177°C (-62°F to +350°F), with an extended temperature range of up to +218°C (+425°F) for the probe tip.
• Q2: Can the probe be used in high-pressure environments?
  A2: The 3300 XL probe is designed to seal differential pressure with a Viton® O-ring, but it is not pressure tested before shipment. For specific pressure needs, consult with the custom design department.
• Q3: What is the power consumption of the probe?
  A3: The probe requires a power supply of -17.5 Vdc to -26 Vdc with a maximum current consumption of 12 mA.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
