Description

The Bently Nevada 330101 – 00 – 75 – 15 – 02 – 05 3300 XL 8 mm Probe is a top – tier sensing device. Its patented TipLoc and CableLoc designs enhance durability, and the FluidLoc option provides leak – prevention. Ideal for applications that demand robust and reliable performance. Contact [email protected] for more information.

Technical Data

• General
  • Brand: Bently Nevada
  • Model: 330101 – 00 – 75 – 15 – 02 – 05
  • Origin: U.S.A
  • COO Option: Available
  • Approvals: CSA, ATEX, IECEx
• Dimensions
  • Unthreaded Length: 0.0 in
  • Overall Case Length: 7.5 in
  • Total Length: 1.5 m (4.9 ft)
• Connector & Cable
  • Connector: 02 – Miniature coaxial ClickLoc connector
  • Cable: Standard cable
• Electrical
  • DC Resistance (1.5 m probe): 7.73 ± 0.50 Ω
  • Capacitance (extension cable): 69.9 pF/m (21.3 pF/ft) typical
• Performance
  • Linear Range: 2 mm (80 mils)
  • Radial Vibration Gap: -9 Vdc [1.27 mm (50 mils)]
  • Incremental Scale Factor (ISF)
    • 5 or 1 – meter System: 7.87 V/mm (200 mV/mil) ± 5%
    • 9 – meter & Extended Temperature Range Systems: 7.87 V/mm (200 mV/mil) ± 6.5%
• Materials
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 303 or 304 stainless steel (SST)
• Weight: 323 g/m (11.4 oz)
• Temperature Range
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe
    • Probe Tip: -52°C to +218°C (-62°F to +425°F)
    • Probe Cable and Connector: -51°C to +260°C (-60°F to +500°F)

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
