Overview

The Bently Nevada 330103-00-04-10-02-05 represents precision engineering for industrial vibration monitoring. Designed for reliability, this 8mm proximity probe features a compact 4mm case length while maintaining robust performance. Furthermore, it meets stringent CSA, ATEX, and IECEx safety standards for hazardous environments.

Technical Specifications

• • Brand: Bently Nevada
  • Model: 3300XL 8mm Proximity Probe (330103-00-04-10-02-05)
  • Part Number Breakdown:
    • 00: 0mm unthreaded section
    • 04: 4mm overall case length
    • 10: 1.0 meter cable length
    • 02: Miniature coaxial ClickLoc connector
    • 05: CSA/ATEX/IECEx certified
  • Construction: PPS tip with 303/304 stainless steel housing
  • Electrical: 7.59Ω ±0.50 resistance (1m cable)
  • Measurement Range: 0.25-2.3mm linear range (-1 to -17Vdc)
  • Frequency Response: 0 to 10 kHz (±3dB)
  • Temperature Drift: ±0.05%/°C (typical)
  • Output Sensitivity: 200 mV/mil (7.87 V/mm)
  • Phase Shift: ≤5° at 5 kHz

Environmental Specifications

• IP Rating: IP67 when properly installed
• Chemical Resistance: Withstands most oils and coolants
• EMI/RFI Protection: 10 V/m (80 MHz to 1 GHz)
• Altitude Rating: 3000 m maximum
• Thermal Shock: Withstands 5 cycles (-40°C to +85°C)

Contact Information

For any inquiries, please contact: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
