330103-00-09-10-02-00 | Proximity Probes – Bently Nevada

Product Overview

The Bently Nevada 330103-00-09-10-02-00 is a high-precision 8mm proximity probe designed for critical vibration monitoring in industrial machinery. Featuring a rugged stainless steel construction and advanced sensing technology, this probe delivers reliable performance in demanding environments from -52°C to +177°C.

Technical Specifications

• Manufacturer: Bently Nevada
• Model Number: 330103-00-09-10-02-00
• Configuration Options:
  • 00: 0mm unthreaded length (flush mount)
  • 09: 9mm overall case length
  • 10: 1.0 meter cable length
  • 02: Miniature coaxial ClickLoc connector
  • 00: Standard certification

Key Features

• 9mm compact case design for space-constrained installations
• Stainless steel housing (AISI 303/304) with PPS probe tip
• Viton O-ring seal for pressure differential protection

Performance Data

• Linear measurement range: 0.25-2.3mm (10-90 mils)
• Recommended gap setting: 1.27mm at -9Vdc output
• Humidity resistance: <3% ASF change at 93% RH

Certifications

• ATEX/IECEx: Ex ia IIC T5…T1 Ga (with barriers)
• UL/cUL: Class I, Division 2, Groups A-D

Applications

Ideal for monitoring turbines, compressors, pumps and other rotating equipment in power generation, oil & gas, and industrial applications.

Contact Information

For any inquiries, please contact: [email protected]

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
