330104-06-14-10-02-00 3300 XL Proximity Probe Bently Nevada

Overview

The Bently Nevada 3300 XL 8 mm Proximity Probe (Product No. 330104-06-14-10-02-00) is designed to provide high-performance measurements in various industrial applications. Manufactured in the U.S.A., these probes are known for their durability and accuracy.

Technical Specifications

• Brand: Bently Nevada
• Model: 330104-06-14-10-02-00
• Product Type: 8 mm Proximity Probes
• Overall Case Length Option: 14 = 140 mm
• Unthreaded Length Option: 06 = 60 mm
• Total Length Option: 10 = 1.0 metre (3.3 feet)
• Connector and Cable-Type Option: 02 = Miniature coaxial ClickLoc™ connector, standard cable
• Agency Approval Option: 00 = Not required
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Weight: 0.323 kg
• Probe Pressure: Designed to seal differential pressure using a Viton® O-ring
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe:
    • Tip: -52°C to +218°C (-62°F to +425°F)
    • Cable and Connector: -51°C to +260°C (-60°F to +500°F)
• Power Requirements:
  • -17.5 Vdc to -26 Vdc at 12 mA maximum consumption
  • -23 Vdc to -26 Vdc with barriers
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ω
• Probe Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity for up to 56 days

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
