330105-02-12-05-02-00 3300 XL 8 mm Proximity Probe

Overview

The Bently Nevada 330105-02-12-05-02-00 is designed for high-precision vibration monitoring, offering reliable and accurate measurements in industrial applications. This reverse mount version ensures easy installation and secure operation in challenging environments. The probe is engineered to withstand extreme conditions, with various temperature and environmental specifications that make it ideal for use in rotating machinery, motors, and other industrial assets.

Features

• Model: 3300 XL 8 mm Reverse Mount Probe
• Connector Type: Miniature ClickLoc coaxial connector (option -02)
• Temperature Range:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range Probe: -52°C to +218°C (-62°F to +425°F) for the probe tip; -51°C to +260°C (-60°F to +500°F) for the probe cable and connector
• Length: 0.5 meter (1.6 feet)
• Dimensions: 20.4 cm x 22.2 cm x 3.7 cm
• Weight: 0.23 kg
• Maximum Thread Engagement Length: 3/8-24, 0.563 inches
• Agency Approval: Not required (-00 option)
• Made in U.S.A.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Reverse Mount Probe
• Product Code: 330105-02-12-05-02-00
• Temperature Range:
  • Standard: -52°C to +177°C (-62°F to +350°F)
  • Extended: -52°C to +218°C for probe tip, -51°C to +260°C for cable and connector
• Connector: Miniature ClickLoc Coaxial
• Total Length: 0.5 meters (1.6 feet)
• Weight: 0.23 kg
• Maximum Thread Engagement: 0.563 inches (3/8-24)

This probe is suitable for environments requiring high precision and robust performance across a wide range of temperatures. It ensures easy interchangeability with the 3300 XL system, provided it is calibrated with an AISI 4140 steel target.

FAQ

Q1: What is the maximum operating temperature of the Bently Nevada 3300 XL 8 mm Reverse Mount Probe?

• The standard operating temperature for this probe is between -52°C and +177°C. However, the extended temperature range option allows for use up to +218°C at the probe tip and +260°C for the probe cable and connector.

Q2: What is the total length of this probe?

• The probe measures 0.5 meters (1.6 feet), which is ideal for various industrial setups.

Q3: Can I use this probe with any target material?

• For optimal performance and accuracy, this probe is calibrated with an AISI 4140 steel target. Calibration with other materials may affect the system’s accuracy.

Q4: What is the probe’s connector type?

• The probe is equipped with a Miniature ClickLoc coaxial connector, offering secure and reliable connectivity.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
