330105-02-12-15-02-05 Bently Nevada Reverse Mount Probe

Overview

The Bently Nevada 330105-02-12-15-02-05 3300 XL 8mm Proximity Transducer System is a high-performance solution designed to deliver reliable and accurate proximity measurements in industrial machinery monitoring. Engineered with robust materials and advanced features, this system is suitable for a variety of applications, including vibration monitoring and shaft position measurements. Notably, its components ensure superior performance, even under challenging conditions.

Key Features

• Brand: Bently Nevada
• Model: 3300 XL 8mm Proximity Transducer System
• Product No.: 330105-02-12-05-02-05
• Probe Tip Material: Polyphenylene sulfide (PPS) for enhanced durability.
• Probe Case Material: AISI 303 or 304 stainless steel (SST), ensuring robustness.
• Connector Option: Miniature ClickLoc coaxial connector for secure and quick connections.
• Weight: 0.323 kg, allowing for easy installation.
• Suffix Breakdown
  • 330105: Indicates the product model.
  • 02: Connector type (Miniature ClickLoc coaxial).
  • 12: Probe length (1.2 meters).
  • 05: Agency approvals (multiple approvals).
  • 02: Probe material (AISI 303/304 SST).
  • 05: Additional options (e.g., sealing and temperature range).

Technical Specifications

• Total Length Option: 0.5 meters (1.6 feet).
• Maximum Thread Engagement Length: 3/8-24, 0.563 inches.
• Nominal Probe DC Resistance:
  • 1.5 m probe length: 7.73 ± 0.50 Ω.
• Torque Specifications:
  • Maximum Rated Torque: 22.6 N•m (200 in•lbf).
  • Recommended Torque: 7.5 N•m (66 in•lbf).
• Temperature Ranges:
  • Standard Probe: -52°C to +177°C (-62°F to +350°F).
  • Extended Temperature Probe:
    • Probe Tip: -52°C to +218°C (-62°F to +425°F).
    • Probe Cable/Connector: -51°C to +260°C (-60°F to +500°F).
• Sealing Material: Viton® O-ring for differential pressure sealing. Custom pressure testing is available upon request.

Applications

• Industrial machinery monitoring.
• Vibration analysis and shaft displacement measurement.
• Oil and gas, power generation, and manufacturing industries.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
