330105-02-12-20-12-05 | Bently Nevada Reverse Mount Probe

Overview

The Bently Nevada 3300 XL 8 mm Reverse Mount Probes (Product No. 330105-02-12-20-12-05) are renowned for their superior performance in vibration and displacement measurement systems. Designed and manufactured in the U.S.A., these probes provide reliable functionality even in demanding industrial environments. Enhanced with patented technologies such as TipLoc and CableLoc, they deliver improved durability and system integrity. Additionally, they support optional features like the FluidLoc cable option, which prevents fluid leakage through the cable.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Reverse Mount Probes
• 330105-02-12-20-12-05 Breakdown:
  • 330105-02-12: 3/8-24 UNF threads
  • 20: Probe length – 2.0 meters (6.6 feet)
  • 02: Miniature ClickLoc™ coaxial connector
  • CN: Country-specific agency approvals
• Weight: 0.323 Kg
• Made in: U.S.A.
• Target Specifications:
  • Minimum target size: 15.2 mm (0.6 in) diameter (flat target)
  • Standard Target Material: AISI 4140 steel
• Environmental Ratings:
  • Standard Probe Temperature Range: -52°C to +177°C (-62°F to +350°F)
  • Extended Temperature Range: Probe tip: -52°C to +218°C (-62°F to +425°F); Cable and connector: -51°C to +260°C (-60°F to +500°F)
• Material Composition:
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 303 or 304 stainless steel
• Thread Engagement:
  • Maximum Length: 3/8-24 thread, 0.563 in
• Sealing:
  • Pressure seal: Viton® O-ring (not pressure-tested unless custom ordered)
• Torque Ratings:
  • Recommended: 7.5 N•m (66 in•lbf)
  • Maximum: 22.6 N•m (200 in•lbf)

FAQ

• 1. What is the meaning of the suffix in the product number (CN)?
  The “CN” suffix indicates that the product complies with country-specific agency approvals. Refer to the Quick Reference Guide and Field Notification Letter for details.
• 2. What type of connector is used in this probe?
  The probe features a Miniature ClickLoc™ coaxial connector for secure and reliable connections.
• 3. Can the probe withstand high temperatures?
  Yes, the extended temperature range allows the probe tip to operate up to +218°C (+425°F), while the cable and connector can withstand up to +260°C (+500°F).

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
