Product details
Overview
The Bently Nevada 3300 XL 8 mm Reverse Mount Probe (Product No. 330106-05-30-10-12-00) is a durable, high-performance proximity probe designed for vibration and displacement measurements in industrial machinery monitoring. Manufactured in the USA, it is engineered to provide precise and reliable data for critical equipment, ensuring optimal performance and safety in demanding environments.
Technical Specifications
- Brand: Bently Nevada
- Model: 330106-05-30-10-12-00
- Suffix Breakdown:
- Length Option (10): 1.0 meter (3.3 feet) cable length.
- Connector Option (12): Miniature ClickLoc™ with FluidLoc® cable.
- Agency Approval Option (00): Not required.
- Suffix Breakdown:
- Power Requirements:
- Input Voltage: -17.5 Vdc to -26 Vdc.
- Consumption: 12 mA maximum.
- Requires -23 Vdc to -26 Vdc with barriers.
- Output Resistance: 50 Ω.
- Probe Pressure: Designed for differential pressure sealing with Viton® O-ring, but not pressure-tested prior to shipment.
- Supply Sensitivity: Less than 2 mV output voltage change per volt input change.
Frequently Asked Questions (FAQ)
Q1: What is the significance of the 8 mm probe design?
A: The 8 mm probe provides a thicker encapsulation of the coil, ensuring greater durability and resistance to physical damage. The larger body diameter enhances robustness.
Q2: Is the probe pressure-tested before shipment?
A: No, the probes are not pressure-tested. However, they feature a Viton® O-ring to seal differential pressure. For specific testing requirements, contact the manufacturer.
Q3: What are the recommended input voltage parameters?
A: The probe operates optimally at -23.5 Vdc to -26 Vdc with barriers. Deviating from these parameters can affect the linear range.
Q4: What is the advantage of the ClickLoc™ connector?
A: The Miniature ClickLoc™ coaxial connector offers secure and reliable connections, along with enhanced durability for industrial use.
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
