330106-05-30-10-12-05 Bently Nevada | Reverse Mount Probes

Overview

The Bently Nevada 330106-05-30-10-12-05 Reverse Mount Probe is designed for high-precision vibration monitoring in industrial applications. Made in the U.S.A, this probe is suitable for installations that require high durability and reliability. With a range of features including agency approvals and multiple connector options, this probe is engineered for optimal performance in demanding environments.

Technical Specifications

• Brand: Bently Nevada
• Model: 330106-05-30-10-12-05
• Product Type: Reverse Mount Probe
• Made In: U.S.A

Physical Dimensions:

• Probe Case Dimensions: 20.4 cm x 22.2 cm x 3.7 cm
• Weight: 0.323 kg

Electrical Specifications:

• Nominal Probe DC Resistance:
  • Resistance (RPROBE) from center conductor to outer conductor: 7.59 ± 0.50 ohms
• Connector Option:
  • 12 Miniature ClickLoc coaxial connector
  • FluidLoc cable (option –12)
  • Note: FluidLoc cable is typically unnecessary for most installations due to the probe sleeve. Evaluate application needs before choosing this option.

Mechanical Specifications:

• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Maximum Probe Case Torque:
  • Rated torque: 22.6 N•m (200 in•lbf)
  • Recommended torque: 7.5 N•m (66 in•lbf)
• Maximum Length of Thread Engagement: 15 mm (M10 x 1 thread)

Temperature Range:

• Operating Temperature:
  • Standard probe: -52°C to +177°C (-62°F to +350°F)
  • Extended temperature range:
    • Probe tip: -52°C to +218°C (-62°F to +425°F)
    • Probe cable and connector: -51°C to +260°C (-60°F to +500°F)
  • Caution: Temperatures below -34°C (-30°F) may cause premature failure of the pressure seal.

Pressure Sealing:

• Designed to maintain differential pressure between the probe tip and case
• Sealing material: Viton® O-ring
• Pressure Test: Probes are not pressure-tested before shipment. Contact Bently Nevada for custom pressure tests.

Agency Approvals:

• CSA, ATEX, IECEx approvals available for this probe model

Frequently Asked Questions (FAQ)

1. What is the maximum temperature this probe can handle?
   • The probe can operate within the range of -52°C to +177°C for standard use, and up to +218°C for the probe tip under extended temperature conditions.
2. What is the warranty on this product?
   • Bently Nevada typically offers a standard warranty; please contact customer support for specific terms related to this product.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
