330130-035-12-00 FluidLoc Cable | Bently Nevada

Overview:

The 3300 XL Standard Extension Cable (Model: 330130-035-12-00) from Bently Nevada is a high-performance, factory-original extension cable designed for use with the 3300 XL Proximitor Sensor and 8 mm probes. Featuring a durable construction, it ensures reliable signal transmission and robust performance, particularly in environments requiring protection against liquids like turbine oils. The cable is equipped with a FluidLoc cable option for enhanced sealing, ensuring long-term reliability.

This extension cable, available in a 3.5-meter (11.5 feet) length, is ideal for use in industrial applications, ensuring secure connectivity between probes and monitoring equipment. It is backed by a 12-month factory warranty.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL Standard Extension Cable
• Part Number: 330130-035-12-00
• Cable Length: 3.5 meters (11.5 feet)
• Connector Option: FluidLoc cable with connector protector
• Nominal Extension Cable DC Resistance:
  • Resistance (RCORE) from Center Conductor to Center Conductor: 0.77 ± 0.12 Ω (for 3.5 meters)
  • Resistance (RJACKET) from Outer Conductor to Outer Conductor: 0.23 ± 0.05 Ω (for 3.5 meters)
• Cable Capacitance: 69.9 pF/m (21.3 pF/ft), typical
• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG), with 3-conductor shielded triad cable recommended
• Power Supply: -17.5 Vdc to -26 Vdc; operation at -23.5 Vdc or more positive may reduce linear range
• Operating Sensitivity: Less than 2 mV change in output per volt change in input voltage
• Linear Range: From approximately 0.25 mm (10 mils) to 2.3 mm (90 mils), with a gap of 1.27 mm (50 mils) from the target
• Maximum Cable Length: 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitoring equipment
• Performance: Applies to systems with 3300 XL components using AISI 4140 steel targets

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
