The Bently Nevada 330130-040-03-00 is a robust extension cable designed for reliable operation in demanding industrial environments. This cable, part of the 3300 XL Standard series, integrates advanced features for improved durability and performance. Its compatibility with 3300 XL 8 mm probes ensures precise measurements and enhanced system efficiency.
Key Features and Model Configuration
- Model: 330130 – 3300 XL Standard Extension Cable.
- Cable Length Option: -040 – 4.0 meters (13.1 feet).
- Connector and Cable Protection Option: -03 – Armored cable with connector protectors for added durability.
- Agency Approval Option: -00 – Not required.
This model is equipped with the FluidLoc optional feature to prevent oil or liquid seepage through the cable’s interior.
Technical Specifications
- Material:
- Constructed using 75 Ω triaxial cable with fluoroethylene propylene (FEP) insulation.
- Available in probe lengths of 0.5 m, 1 m, 1.5 m, 2 m, 5 m, or 9 m.
- Temperature Range:
- Operates effectively between -51°C to +177°C (-60°F to +351°F).
- Electrical Properties:
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
- Output Resistance: 50 Ω.
- Field Wiring: Accepts 16 to 24 AWG shielded triad cable for field wiring up to 305 meters (1,000 feet).
- Power Requirements:
- Operates with a -17.5 Vdc to -26 Vdc power supply, consuming a maximum of 12 mA.
- Weight: Approximately 0.45 kg.
FAQ
- What does the suffix “-040-03-00” indicate?
- The “-040” specifies a 4.0-meter cable length, the “-03” represents armored protection, and “-00” means no agency approvals are required.
- What are the benefits of the FluidLoc option?
- It prevents liquid leakage through the cable, ensuring longevity and reliability in environments prone to oil exposure.
- Can the cable handle extreme temperatures?
- Yes, the cable operates in a wide temperature range from -51°C to +177°C.
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
