330130-070-10-05 | Bently Nevada | FluidLoc Extension Cable

Overview:

The Bently Nevada 330130-070-10-05 Extension Cable is designed for use with the 3300 XL proximity sensor series. Made in the U.S.A, it is a high-performance extension cable that ensures reliable operation in demanding industrial environments. This 7.0-meter (22.9 feet) cable comes with various approval certifications, including CSA, ATEX, and IECEx.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330130-070-10-05
• Cable Length: 7.0 meters (22.9 feet)
• Cable Type: FluidLoc cable (optional)
• Connector Protector: Silicone tape or FluidLoc cable (for oil and liquid protection)
• Approvals: CSA, ATEX, IECEx
• Weight: 0.238 kg (34 g/m)
• Resistance:
  • RCORE (Center Conductor to Center Conductor): 1.54 ± 0.23 Ω (for 7 meters)
  • RJACKET (Outer Conductor to Outer Conductor): 0.46 ± 0.09 Ω (for 7 meters)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Maximum Cable Length: 305 meters (1,000 feet) from sensor to monitor
• Field Wiring: Compatible with 0.2 to 1.5 mm² (16 to 24 AWG) cables, recommended triad shielded cable
• Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils)
• Supply Voltage: Requires -17.5 Vdc to -26 Vdc for nonincendive circuits, or -23 Vdc to -26 Vdc with barriers

FAQ:

• Q: What is the maximum recommended length for the extension cable?
• A: You can use the cable with a maximum length of 305 meters (1,000 feet) from the 3300 XL proximity sensor to the monitor.
• Q: What approvals does the cable have?
• A: The cable holds CSA, ATEX, and IECEx approvals, ensuring it meets global safety standards.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
