330130-080-11-00 Bently Nevada | FluidLoc Cable

Overview

The Bently Nevada 330130-080-11-00 is an extension cable designed specifically for use with 3300 XL 8 mm Proximitor sensors. Crafted in the U.S.A., this cable features a durable construction ideal for a variety of industrial applications, ensuring reliable performance even in challenging environments. Customers can request a Certificate of Origin (COO) for this product.

Technical Specifications

• Manufacturer: Bently Nevada
• Product No.: 330130-080-11-00
• Product Type: Extension Cable
• Cable Length: 8.0 meters (26.2 feet)
• Connector Protector & Cable Option: Armored FluidLoc cable (designation: 11)
• Weight:
  • 34 g/m (0.4 oz/ft). 0.272 kg (0.6 lbs)
• Approvals:
  • CSA
  • ATEX
  • IECEx
• Electrical Specifications:
  • Nominal DC Resistance:
    • Center Conductor to Center Conductor (RCORE):
      • 8.0 m: 1.76 ± 0.26 Ω
    • Outer Conductor to Outer Conductor (RJACKET):
      • 8.0 m: 0.53 ± 0.11 Ω
• Power Requirements:
  • -17.5 Vdc to -26 Vdc with nonincendive circuit per installation drawing 140979
  • 12 mA maximum consumption
  • -23 Vdc to -26 Vdc with barriers
  • Exceeding -23.5 Vdc may reduce linear range
• Output Parameters:
  • Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
  • Output Resistance: 50 Ω
  • Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Field Wiring:
  • Wire Size: 0.2 to 1.5 mm² (16 to 24 AWG)
  • Recommended: 3 conductor shielded triad cable
  • Maximum length between Proximitor Sensor and the monitor: 305 meters (1,000 feet)
• Linear Range:
  • 2 mm (80 mils)
  • Begins at approximately 0.25 mm (10 mils) from target, extending to 2.3 mm (90 mils) (approximately -1 to -17 Vdc

FAQ

Q: What is the maximum length of the extension cable?
A: The maximum length is 8.0 meters (26.2 feet).

Q: What are the approvals for this extension cable?
A: The extension cable holds CSA, ATEX, and IECEx approvals.

Q: Can this cable be used in high-temperature environments?
A: Performance characteristics are specified for the range of +18˚C to +27˚C (+64˚F to +80˚F).

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
