330180-X0-05 Bently Nevada | 3300 XL Proximitor Sensor

Overview

The Bently Nevada 3300 XL 330180-X0-05 Proximitor Sensor is a highly sensitive, robust, and lightweight sensor designed for industrial applications such as vibration measurement and machine condition monitoring.

Features

• High Sensitivity: Output resistance of 50 Ω, with sensitivity less than 2 mV change in output voltage per volt change in input voltage.
• Robust Construction: Made from A308 aluminum, ensuring durability.
• Temperature Range: Operates effectively between -51 °C to +100 °C (-60 °F to +212 °F) and can be stored from -51 °C to +105 °C (-60 °F to +221 °F).
• Lightweight Design: Weighs only 0.246 kg (8.67 oz).

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 330180-X0-05
• Suffix Meaning: X0 indicates the total length and mounting option.
• Product Type: Proximitor Sensor
• Power Supply: Requires -17.5 Vdc to -26 Vdc with a maximum consumption of 12 mA. Operation beyond -23.5 Vdc may reduce linear range.
• Altitude Limit: Maximum operating altitude of 2000 meters.
• Probe Compatibility: Accepts one non-contacting 3300-series 5 mm, 3300 XL 8 mm Proximity Probe and Extension Cable.
• Agency Approvals: CSA, ATEX, and IECEx approvals available (05).
• Applications: Ideal for use in vibration measurement, machine condition monitoring, and other industrial measuring tasks.

Available Length and Mounting Options: X0

• 10 – 10 m (3.3 ft) system length, panel mount
• 50 – 5 m (16.4 ft) system length, panel mount
• 90 – 9 m (29.5 ft) system length, panel mount

FAQ

1. What type of probe is compatible with the Bently Nevada 3300 XL Proximitor Sensor?
The sensor accepts one non-contacting 3300-series 5 mm or 3300 XL 8 mm Proximity Probe and Extension Cable.

2. What is the operating temperature range of this sensor?
It operates effectively between -51 °C to +100 °C (-60 °F to +212 °F).

3. What are the power requirements?
It requires a power supply of -17.5 Vdc to -26 Vdc, with a maximum current consumption of 12 mA.

4. Can I use this sensor at high altitudes?
Yes, it is designed for maximum operation at altitudes of up to 2000 meters.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
