330190-085-00-CN Bently Nevada | ETR Extension Cable

Bently Nevada ETR Extension Cable – Overview & Specifications

The Bently Nevada 330190-085-00-CN is an extension cable designed for use with the 3300 XL 8mm Proximity Transducer System, providing a reliable connection between the sensor and the control system.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330190-085-00-CN
• Product Type: 3300 XL 8mm Proximity Transducer System Extension Cable
• Cable Length Option: 085 = 8.5 meters (27.9 feet)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Extension Cable Material: 75Ω triaxial, FEP (Fluoroethylene Propylene) insulated
• Connector Material: Gold-plated brass or gold-plated beryllium copper for enhanced conductivity and durability
• Temperature Range: Standard or extended temperature options
• Cable Strength:
  • Maximum tensile strength of 330 N (75 lbf) from probe case to probe lead
  • Maximum tensile strength of 270 N (60 lbf) at probe lead to extension cable connectors
• Armor: Optional flexible AISI 302 or 304 SST (Stainless Steel) with FEP outer jacket for added protection

FAQ

1. What is the maximum length available for this extension cable?
   • This model comes in an 8.5-meter (27.9 feet) length.
2. Can I use this extension cable in extreme temperature conditions?
   • Yes, the cable offers both standard and extended temperature range options.
3. Is the cable durable for heavy-duty industrial use?
   • Yes, the cable is designed with a high tensile strength and optional armor for enhanced durability.

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
