330500-06-00 Bently Nevada Velomitor Piezo-velocity Sensor

Overview

The Bently Nevada Velomitor Piezo-Velocity Sensor, model number 330500-06-00, is designed for industrial applications requiring precision and reliability. Its sturdy construction and high-performance specifications make it suitable for various monitoring and measurement tasks.

Features

• Certificate of Origin (COO): Can be added on request.
• Mounting Thread Adapter Option: 06 = 5/8 – 18 UNF.
• Agency Approval Option: 00 = Not required.
• Connector: 2-pin Mil-C-5015 hermetically sealed, 316L stainless steel shell.

Technical Specifications

• Brand: Bently Nevada.
• Model: 330500-06-00.
• Suffix Meaning:
  • 06: 5/8 – 18 UNF Mounting Thread Adapter Option.
  • 00: No agency approval required.
• Mounting Torque: 32-46 kg cm (24-40 in-lb) max.
• Case Material: 316L stainless steel.
• Height: 63.2 mm (2.49 in).
• Diameter: 25.3 mm (0.995 in).
• Weight: 142 grams (5.0 oz), typical.
• Polarity: When the sensor case motion is toward the connector, Pin A becomes positive with respect to Pin B.

FAQ

• What is the mounting torque range?
• The mounting torque range is 32-46 kg cm (24-40 in-lb) max.
• What are the connector specifications?
• The connector is a 2-pin Mil-C-5015 hermetically sealed, with a 316L stainless steel shell.
• What materials are used in the sensor’s construction?
• The sensor’s case is made from 316L stainless steel.

For more detail information: 330500-Datasheet
