Overview
The Bently Nevada 3300 XL 11 mm Extension Cable, part number 330730-040-12-00, is designed for reliable and robust operation in challenging industrial environments. Made in the U.S.A, this cable offers extended connectivity for 3300 XL probes and is equipped with FluidLoc cable options to prevent fluid leakage, ensuring durability in harsh conditions. It features a flexible AISI 302 stainless steel armor option, which provides added protection against physical stress and harsh environments. The extension cable can be used in applications that require high precision and reliability in vibration monitoring systems.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 11 mm Extension Cable
- Product No.: 330730-040-12-00
- Operating Temperature Range: -51°C to +177°C (-60°F to +351°F)
- Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
- Armor (optional): Flexible AISI 302 SST with FEP outer jacket
- Resistance (RCORE): 1.0 ± 0.25 ohms (for 4.0 m length)
- Resistance (RJACKET): 0.3 ± 0.1 ohms (for 4.0 m length)
- Tensile Strength: 330 N (75 pounds) probe case to probe lead
- Connector Material: Gold-plated brass
- Cable Material: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated
- Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG) [0.25 to 0.75 mm² (18 to 23 AWG) with ferrules]
- Recommended Gap Setting: 2.5 mm (100 mils)
Ordering Information
- Model Number: 330730-040-12-00
- Cable Length: 4.0 meters (13.1 feet)
- Connector Type: FluidLoc with connector protector option
- Armor Option: Flexible AISI 302 SST with FEP outer jacket
FAQ
- What is the maximum cable length for the 3300 XL Extension Cable?
The maximum recommended length is 305 meters (1,000 feet) between the 3300 XL Probe and the monitoring system. - Is the cable armored?
Yes, the extension cable comes with an optional flexible AISI 302 SST armor with a FEP outer jacket for extra durability.
For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
