330730-080-03-00 Armored Extension Cable | Bently Nevada

Overview:

The Bently Nevada 3300 XL 11 mm Extension Cable (Part No. 330730-080-03-00) is designed for high-performance applications in industrial environments. Made in the USA, this extension cable offers flexibility and durability for use with 3300 XL Proximity Probes. It is available in multiple configurations, including armored options with a connector protector for enhanced environmental protection. The 8.0-meter (26.2 feet) cable length ensures optimal reach in various installations, while the robust construction supports reliable signal transmission in harsh conditions.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Extension Cable
• Product No.: 330730-080-03-00
• Temperature Range: Operating and storage temperatures from -52°C to +177°C (-62°F to +351°F)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Cable Armor: Flexible AISI 302 SST with FEP outer jacket (optional)
• Extension Cable Resistance:
  • RCORE (Center Conductor to Center Conductor): 2.0 ± 0.5 ohms
  • RJACKET (Coaxial Conductor to Coaxial Conductor): 0.6 ± 0.2 ohms
• Extension Cable Material: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated
• Connector Material: Gold-plated brass
• Tensile Strength (Maximum Rated):
  • 330 N (75 pounds) probe case to probe lead
  • 270 N (60 pounds) at probe lead to extension cable connectors
• Maximum System Length: 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitor

Ordering Information:

When ordering, specify the desired cable length, armored cable option, and whether a connector protector is required for the installation environment. The following part number details the options:

• Part No.: 330730-080-03-00
  • 080: 8.0 meters cable length
  • 03: Armored cable with connector protector
  • 00: No agency approval required

FAQ:

1. Is the cable resistant to oil?
   Silicone tape is included with each cable, though it is not recommended for use in applications where the connection will be exposed to turbine oil.
2. What is the maximum length of the extension cable?
   The cable supports up to 305 meters (1,000 feet) in system length when connecting the probe to the monitor.
3. What is the difference between the armored cable and the standard version?
   The armored cable offers additional protection against external damage, ideal for harsh or physically demanding environments.

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
