330730-080-10-CN 11 mm Extension Cable | Bently Nevada

Overview:

The Bently Nevada 3300 XL 11 mm Extension Cable (Product No. 330730-080-10-CN) is an essential component for enhancing the performance and durability of your monitoring system. Designed for use with 3300 XL Proximity Probes, this extension cable provides reliable and secure connections over long distances. It is ideal for applications in harsh environments due to its flexible and armored construction, ensuring long-term stability and protection.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Extension Cable
• Connector Material: Gold-plated brass
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Extension Cable Armor: Optional Flexible AISI 302 SST with FEP outer jacket
• Resistance (Core): 2.0 ± 0.5 ohms
• Resistance (Jacket): 0.6 ± 0.2 ohms
• Tensile Strength: 330 N (75 pounds) at probe case to probe lead; 270 N (60 pounds) at probe lead to extension cable connectors
• Operating and Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG) [0.25 to 0.75 mm² (18 to 23 AWG) with ferrules]
• Extension Cable Material: 75 Ω triaxial, fluoroethylene propylene (FEP) insulated
• Maximum Length: 305 meters (1,000 feet) between 3300 XL Proximitor Sensor and monitor
• Linear Range: 4.0 mm (160 mils)
• Weight: 0.36kg

Ordering Information:

• Product No.: 330730-080-10-CN
• Cable Length: 8.0 meters (26.2 feet)
• Connector and Cable Option: 10 FluidLoc Cable
• Agency Approval: CN Country Specific

FAQ:

1. What is the maximum length the cable can reach?
   The extension cable supports a maximum length of 305 meters (1,000 feet) between the probe and monitor.
2. What is the recommended temperature range for operation?
   The extension cable operates between -52°C to +177°C (-62°F to +351°F).
3. Can the cable be used in a high-moisture environment?
   Yes, the cable has optional connector protectors that provide additional protection in moist environments.
4. Is the FluidLoc cable option required?
   While the FluidLoc option is not mandatory, it is recommended for preventing fluid leakage in machinery.
5. What is the extension cable’s capacitance?
   The capacitance is 69.9 pF/m (21.3 pF/ft) typical, ensuring minimal signal loss over long distances.

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
