330780-92-00 3300 XL Proximitor Sensor | Bently Nevada

Overview:

The Bently Nevada 3300 XL 11 mm Proximitor Sensor, part number 330780-92-00, offers precise vibration and position measurements. Engineered for high-performance applications, this sensor excels in high-density installations. Its slim design enables easy mounting on both DIN rails and traditional panel configurations, providing flexibility for various setup needs. With superior RFI/EMI immunity, this sensor provides enhanced protection against high-frequency radio signals, ensuring reliable operation in industrial environments.

Technical Specifications:

• Brand: Bently Nevada
• Model: 3300 XL 11 mm Proximitor Sensor
• Product Number: 330780-92-00
• Material: A380 Aluminum housing
• Dimensions (HxWxD): 6.35 cm x 6.12 cm x 8.13 cm
• Temperature Range:
  • Operating Temperature: -52°C to +100°C (-62°F to +212°F)
  • Storage Temperature: -52°C to +105°C (-62°F to +221°F)
• Relative Humidity: 100% condensing, non-submersible (when connectors are protected)
• Power Requirements:
  • -17.5 Vdc to -26 Vdc (12 mA max) without barriers
  • -23 Vdc to -26 Vdc with barriers
• Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
• Output Resistance: 50 Ω

Ordering Information:

• Model: 3300 XL 11 mm Proximitor Sensor
• Length Options: 5 meters or 9 meters (including extension cable)
• Target Calibration: Default factory calibration to AISI 4140 steel (other materials available upon request)
• Mounting Options: No mounting hardware included (must be purchased separately)

For more detailed information: 3300 XL 11 mm Proximity Transducer System Datasheet
