330930-045-00-05 Bently Nevada | 3300 NSv Extension Cable

Overview

The Bently Nevada 330930-045-00-05 3300 NSv Extension Cable is a high-performance cable designed for use with the 3300 NSv proximity probes in industrial applications. Built for durability and reliability, this cable ensures secure signal transmission in challenging environments. With a temperature range of -51°C to +177°C (-60°F to +351°F), it is ideal for extreme conditions. The cable comes with multiple approvals and is manufactured using high-quality materials, including FEP-insulated coaxial with a 75Ω impedance.

Key Features:

• Brand: Bently Nevada
• Model: 330930-045-00-05
• Cable Length: 4.5 meters (21.3 feet)
• Material: 75Ω coaxial with FEP insulation
• Operating Temperature: -51°C to +177°C (-60°F to +351°F)
• Resistance: Center conductor: 0.220Ω/m, Shield: 0.066Ω/m
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Approval: Multiple approvals
• Connector Material: Gold-plated brass
• Armor Option: Available with or without stainless steel armor (AISI 302 SST)

Technical Specifications:

• Brand: Bently Nevada
• Product Type: 3300 NSv Extension Cable
• Model Suffix Explanation:
  • “045” indicates a 4.5-meter length.
  • “00” signifies no stainless steel armor.
  • “05” denotes multiple approvals for diverse industrial standards.
• Tensile Strength: 220 N (50 lb) probe case to probe lead, and probe lead to extension cable connectors.
• Cable Material: 75Ω coaxial, FEP-insulated.
• Storage Temperature: -52°C to +177°C (-62°F to +351°F).

FAQ:

1. What is the cable’s maximum tensile strength?
   • The cable has a tensile strength of 220 N (50 lb) for both probe lead and connector attachments.
2. What is the operating temperature range?
   • The cable operates within a temperature range of -51°C to +177°C (-60°F to +351°F), making it suitable for harsh environments.
3. Can I use this cable with the 3300 RAM probe?
   • Yes, the 3300 NSv Extension Cable is compatible with both the 3300 NSv and the 3300 RAM proximity probes.
4. Is there an armored version of the cable available?
   • Yes, the cable comes with an optional stainless steel armor for added durability.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
