330930-045-00-CN Bently Nevada | 3300 NSv Extension Cable

Overview:

The Bently Nevada 3300 NSv Extension Cable (Product No. 330930-045-00-CN) is designed for use with Bently Nevada’s 3300 NSv probe, offering superior mechanical and electrical compatibility with previous models like the 3300 RAM proximity probe. This high-performance extension cable features a 75 Ω coaxial design, insulated with fluoroethylene propylene (FEP), ensuring reliability in challenging environments. It is particularly suitable for industrial applications, including process compressors, with enhanced chemical resistance and robust connectors to prevent loosening and signal degradation.

Features:

• Material: 75 Ω coaxial, FEP-insulated cable for superior durability.
• Connector: Gold-plated brass ClickLoc connectors provide secure, lock-in connections.
• Chemical Resistance: Enhanced resistance compared to older models, making it ideal for process compressor applications.
• Temperature Range: Operates in extreme temperatures from -51°C to +177°C (-60°F to +351°F).
• Tensile Strength: 220 N (50 lb) pull strength ensures secure connections.
• Compatibility: Works seamlessly with 3300 NSv and 3300 RAM probes.

Technical Specifications:

• Brand: Bently Nevada
• Model: 330930-045-00-CN
• Length: 4.5 meters (21.3 feet)
• Cable Armor: None (optional stainless steel armor)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Resistance: Center conductor: 0.220 Ω/m (0.067 Ω/ft); Shield: 0.066 Ω/m (0.020 Ω/ft)
• Operating Temperature: -51°C to +177°C (-60°F to +351°F)
• Storage Temperature: Same as operating temperature.
• Agency Approval: CN (country-specific approvals)
• Made in: U.S.A.

Application:

• Ideal for use in industrial applications, particularly in process compressors and environments requiring enhanced chemical resistance.
• Can be used with both armored and unarmored 3300 NSv probes, available in multiple thread configurations including 1/4-28, 3/8-24, M8X1, and M10X1.
• Compatible with reverse mount probes and offers robust protection for sensitive components.

FAQ:

• Q: What is the maximum operating temperature for this cable?
  • A: The cable can operate within a temperature range of -51°C to +177°C (-60°F to +351°F).
• Q: Does this extension cable come with stainless steel armor?
  • A: The model 330930-045-00-CN does not come with stainless steel armor, but this is an optional feature.
• Q: Can I use this extension cable with previous 3300 RAM probes?
  • A: Yes, this cable is compatible with both 3300 NSv and 3300 RAM probes.
• Q: What approvals does this cable have?
  • A: The cable is country-specific (CN) approved, with additional details available in the Quick Reference Guide.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
