330980-70-05 NSv Proximitor Sensor Bently Nevada

Product Features and Application

• Brand: Bently Nevada
• Model: 330980-70-05
• Sensor Type: NSv Proximitor
• Application: Used primarily for vibration monitoring and proximity measurements in various industrial machinery and systems, including turbines, compressors, and motors.
• Operating Temperature Range: -52°C to +100°C (-62°F to +212°F)
• Storage Temperature Range: -52°C to +105°C (-62°F to +221°F)
• Humidity Resistance: Can operate in 100% condensing humidity when connectors are protected, non-submersible. It has been tested to IEC 68-2-3 damp heat standards.
• Material: Constructed from A380 aluminum, ensuring durability and resistance to corrosion in harsh conditions.

Technical Specifications

• System Length: 7.0 meters (23.0 feet), panel mount configuration. The system length can also be customized to 5 meters.
• Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil), with a tolerance of +12.5%/-20% when measured in increments of 0.25 mm (10 mils) over the 1.5 mm (60 mil) linear range.
• Deviation from Best Fit Straight Line (DSL): Less than ±0.06 mm (±2.3 mils).
• Approval Option: The “-05” suffix indicates Multiple Approvals

FAQ (Frequently Asked Questions)

1. What is the Bently Nevada 330980-70-05 NSv Proximitor Sensor used for?
   This sensor is used for monitoring the proximity and vibration of industrial machinery, ensuring optimal performance and safety in turbines, compressors, and other rotating equipment.
2. What are the temperature limits of the 330XL sensor?
   The operating temperature ranges from -52°C to +100°C (-62°F to +212°F), while the storage temperature can go up to +105°C (-62°F to +221°F).
3. How accurate is the incremental scale factor (ISF)?
   The ISF is 7.87 V/mm (200 mV/mil), with a tolerance of +12.5%/-20% when measured in increments of 0.25 mm (10 mils).
4. Can the sensor operate in high humidity environments?
   Yes, the sensor is designed to operate in 100% condensing humidity when connectors are protected. It is also non-submersible.

For more detailed information: 3300 XL NSv Proximity Transducer System Datasheet
